VMC966 technical parameter | |||
worktable | Worktable size | mm | 1100*550 |
Worktable max.load | kg | 500 | |
T-slot (number*width*distance) |
| 5-18*90 | |
Travel | X-aixs travel | mm | 900 |
Y-aixs travel | mm | 600 | |
Z-aixs travel | mm | 600 | |
Distance from spindle nose to table surface | mm | 100-700 | |
Distance from spindle center to column guideway | mm | 663 | |
Spindle | Spindle transmission type |
| Belt type |
Spindle taper |
| BT 40 φ150 | |
Spindle speed | rpm | 8000 | |
Spindle motor | kw | 7.5/11 | |
Feed Speed | X/Y/Z-aixs rapid feed | m/min | 36\36\36 |
Cutting feed speed | mm/min | 1-10000 | |
Tool magazine | Tool number | pcs | 24 |
Tools change way |
| Disc type ATC | |
Tool change time | s | 1.8 | |
Precision | Positioning precision | mm | ±0.008 |
Reported positioning precision | mm | ±0.005 | |
Package size | mm | 2860x2300x2464 | |
Gross weight | kg | 6000 |
Our company Shandong Dahan Group was established in 2008,which is specializing in Machine tool for more than 40 years,There are more than ten subsidiaries. Our company introduced foreign machine tool design concept, adheres to Taiwan assembly process, innovates and designs on the basis of Taiwan CNC machine tool technology. Our main products are CNC machining center,CNC slant lathe, Its annual turnover In China is more than 200 million RMB ,monthly delivery volume is more than 200 sets. We can supply OEM services. All the products above have passed CE certificates. We can supply those machine tool with good quality and very competitive price.
